HT10000P AC: AC output to 10000 Volts. Delivers 1 through 8 milliamps. Custom outputs to 25 mA.
Logic Controlled, One-button testing. LED indicators. Buzzer upon failure, test terminates. Test termination defeatable by switch on rear panel. Provided with arc detection circuit to properly detect hipot failures.
Rear panel adjustments; leakage limit, ramp time, test time and voltage.
Ergonomic design for safety and ease of use.
High voltage output jack.
Automatic voltage ramp-down circuit eliminates residual voltage.
Designed for product development and laboratory use.
